介电强度 ( Dielectric Strength )

600VAC/1S

绝缘电阻( Insulation Resistance )

100MΩ, 500VDC

环境温度 ( Ambient Temperature )

-20°C   ~   +50°C

绝缘等级 (Insulation Class)

Class B

径向间隙 ( Radial Play )

0.02mm@4N

轴向间隙 ( Axial Play )

0.3mm@4N

最大径向负载 ( Max radial force )

15N距法兰10mm

( 10mm From the flange)

最大轴向负载 ( Max axial force)

5N

极数  ( Number of poles )

2

2

相数  ( Number of phases )

3

3

空载转速 (No load speed)

RPM

40000

12000

空载电流 (No load current)

A

0.2

0.2

额定转矩 ( Rated torque)

mN.m

6

2.5

额定电流 (Rated current)

A

1

0.5

额定速度 ( Rated speed )

RPM

35000

10000

额定功率 ( Rated power )

W

22

2.6

额定效率 (Rated efficiency)

%

80%

75

峰值转矩 ( Peak torque )

mN.m

18

7.5

峰值电流 ( Peak current )

A

2.4

1.5

线电阻 ( Line to line resistance )

ohms@20℃

2.25

1.4

线电感 ( Line to line inductance )

mH

0.13

0.07

转矩常数 ( Torque constant )

mNm/A

7.43

4.7

反电势 ( Back EMF )

Vrms/Krpm

0.55

0.35

外壳-环境热阻( Housing - Ambient thermal resistance)

K/W

8.4

电机热时间常数(Motor thermal time constant)

S

762

绕组最高允许温度(Max temperature of winding)

℃

155

电气时间常数(Electrical time constant)

ms

0.057

黄色(Yellow)

UL1430   AWG26

U相 ( Phase U )

红色( Red)

V相 ( Phase V )

黑色(Black)

W相 ( Phase W )
